Android 8.1 Industrial PDA with for Extra Cold Working Environment
Products Introduction
SK35 is the industrial pda with 3.5 inch IPS screen and keypad. It supports1D/2D barcode Scanning and NFC. With anti-fog coating, SK35 is able to work in situation with temperature from -40℃ to 55℃.
| SK35 Basic Parameters |
| Model | SK35 |
| CPU | Octa-Core 2.0GHz |
| OS | Android 8.1 |
| RAM | 2GB |
| ROM | 16GB |
| Camera | Rear camera 13MP AF (16MP AF Option)；High brightness LED flash,Front Camera 5MP FF |
| Display/type | 3.5”IPS Highlight screen |
| Resolution | 640*960 |
| Touch Panel | 5-point capacitive touch screen |
| Dimensions | 185*70*32mm |
| Weight( with battery) | 300g |
| battery capacity | 19.24Wh |
| Charging | PE fast charge,full charged time<4 hours |
| Bluetooth | BT4.1 BLE |
| Wi-Fi | IEEE 802.11 a/b/g/n 2.4G 5G双频 |
| WWLAN | FDD-LTE B1/B3/B5/B7/B8
TDD-LTE B38/B39/B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
CDMA1x/CDMA2000 BC0/BC1 |
| GPS positioning module | GPS+BD+GLONASS |
| Audio | Front dual stereo speakers, volume 90db ± 3db (test distance 10cm) |
| Sensor | Gsensor, Ambient light sensor, Proximity Sensor, COMPASS |
| Expansion | 2 Micro SIM Cards
1 Micro SD Card Max128G
USB TYPE-C,support OTG,charging 9V 1A |
| Keypad | 35 keys(include 5 side buttons) |
| Notification | Sound, Vbration, LED prompt |
| Operation Temperature | -40℃ ~ +55℃ |
| Storage Temperature | -40℃ ~ +70℃ |
| Humidity | 5%~95% |
| | IP65 |
| Drop Test | 6 sides multiple drop from the height of 1.2 meters to the concrete floor |
| ESD | ±15kV Air Discharge,±8kV Contact Discharge |
| Certificate | CCC |
| NFC | protocol:ISO14443A/B,ISO15693,NFC Reading distance:0~5cm |
Barcode scanning
Support code system | NewLandCM60
EAN13, EAN8, UPCA, UPCE, Code 128, Code 39, Codabar, UCC/EAN128, RSS,ITF, ITF14, ITF6, ISSN, ISBN, Standard 25, Matrix 25,Industrial 25,Plessey, MSI Plessey, Code 11, Code 93, PDF417, QR Code, DataMatrix, AZTEC, 汉信码, Maxicode, Micro QR,Micro PDF417, Composite |
Product Details
Speedata Services
As a listed company from china manufacturer, we support you:
Completely Free SDK and technical support for you.
ODM/OEM customization services according to your needs.
13 months warranty for your devices and other parts. and 6 months for the batteries. Exend warranty,it'll cost 0.5% for each per year.
Free maintenance of the devices and part of accessories replacement in the warranty .if out of the warranty, you'll have to pay the basic cost for them.
FAQ
Question 1: What's your MOQ?
The MOQ of barcode scanner handheld PDA is 1 piece.
Question 2: How long is the delivery time?
The delivery time of barcode scanner goods is different from quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Yes, Of course. We can provide 1 sample Terminal PDA for your testing.
Question 4: What's the total price for 1 sample?
As a manufacturer of barcode scanner terminal PDA,the more you buy, the cheaper it'll be.
The sample price is a little bit higher than the common wholesale price excluding the freight fee.
Question 5: Are you a manufacturer of Handheld PDA?
Yes, we are a R&D orientation China Listed Company, mainly producing industrial PDA Terminal Hardware and as a software solutions supplier with over 8 years' OEM/ODM experience. We are also cooperating with Foxconn Factory.
Question 6: What kind of services do you support ?
We provide you Free SDK and Technical Support for your Barcode Scanner.
We also provide ODM/OEM Customization Services based to your demands.
We support 13 months Warranty for all the device and 6 months for the batteries. Exend warranty, it costs 10% at the first year, and 15% for the second year.
Question 7: What's for payment term and delivery term ?
It's generally 30%-100% TT in advance for all orders. Meanwhile, Paypal or West Union is acceptable.
FOB Shenzhen as Trade Term.
Question 8: Who are your customers?
Our products have been sold to worldwide,especially market in South/North America, Europe, Asia, Africa Mid-east, etc.
The market share is increasing quickly every year and we get more and more positive feedbacks from our customers.
